Executive pump

<< Previous in SPA PUMPS Next in SPA PUMPS >>
Price: $300.00

Personalization

* denotes required field

Horsepower/voltage*
add 2 inch pump unions ?*
add 2-1/2 inch pump unions?*
Is the intake (center) of your pump wet end larger than the discharge (top) ?*

FEATURES:
• Executive wet end designed specifically for 56 frame motors.
• Two double shielded ball bearings with moisture resistant grease for
  quieter operation and longer life.
• Two speed motors have four sets of insulated windings for
  increased efficiency.
• 56 frame motor for added strength, cooler operating temperature
  and longer motor life.
• Large 2" or 2-1/2" intake for improved flow performance & reduced noise.
• Large 6-1/2" diameter wet end for higher head pressure.
• Split capacitor, (start and run) for less energy consumption.
• Thermally protected to extend life expectancy of motor.
• Highly versatile wet end can be rotated every 90°.
• Two year warranty on motor and wet end.




 Horsepower

 Voltage

 AMPS
High Speed

 AMPS
Low Speed

 HZ

 Dimension "A"
(above)

 4

 220V

12.0

4.4

60

10.375"

 5

 220V

16.4

4.8

60

10.375"
